Multiple Rip Saw (MRS-155)

No.

MRS-155

Max. cutting thickness

155mm

Max. cutting width

350mm

Distance from column to link chain center

380mm

Mini. working length

700mm

Max. sawblade diameter

450mm (18")

Mini. sawblade diameter

355mm (14")

Sawblade bore

70 mm (2.756")

Saw arbor diameter

50 mm (1.969")

Saw arbor speed(using 14"-16" saw blade)

2500 rpm

Saw arbor speed(using 16"-18" saw blade)

3000 rpm

Saw arbor motor

75 HP or 100 HP

Variable feed speed

2.5-24 M/min

Powered raise and lower of roller group

1 HP

Feed motor

3 HP

Dust hood dia.

200 mm (optional)

Table height (Pass line)

745 mm

Table area (LxW)

1840 × 790 mm

Overall dimensions (L x W x H)

2340 × 1590 × 1510 mm

Packing dimensions (LxWxH)

2090 × 1720 × 1600 mm

Net weight

2700 kgs

Gross weight

3000 kgs


* Extra Robust 100 HP motor
Great Cutting Thickness of 155 mm (6.1")
Continuous duty 100 HP arbor motor allows deep cutting speeds of thick lumber .

* MRS-155 has a massive cast iron base, composing the majority of total machine weight of 2700kg.
This design provides incredible absorption characteristics under deep cutting, especially while performing thick lumber ripping with a multi-blade set up.

* Precision chain and rails (dip chain) system facilitates accurate cutting operations.
